| Description | CPU | Dual Screen Display |
| Model Number: K3-6L-1 Type: Fan or Fanless Material: Aluminium Alloy Case |
1. Intel Celeron J6412 2. Intel N100 |
1 x HD interface+1 x DP interface(4K@60Hz) |
| RAM Memory | SSD Storage | Network |
| 2 x DDR4 SO-DIMM RAM Slots, support 32GB Max. | 1 x M.2 2280 SATA SSD Slot, 1x 7 pin SATA 3.0 Hard Drive Interface, with a transfer rate of up to 6Gbps |
6 x Intel i226-V network LAN Ports |
| Input/output port | Power & Working Environment | System Supported |
| Switch: 1 x Power On/Off Power: 1 x DC IN USB: 2 x USB3.0, 2 x USB2.0 Display: 1 x HDMI, 1 x DP LAN: 6 x i226-V LAN Console: 1 x RJ45 Console SIM: 1 x SIM Slot Other: 1 x AT/ATX, 1 x RTC/RST1 |
Input: DC100-240V AC/50-60Hz Output: Jack DC 5.5/2.5mm 12V/7A Operating Temperature: -10°C-60°C Relative Humidity: 5%~90%(non-condensing) |
Windows 10 / Windows 11 / Linux |
| Product Dimension | Features | What's in Box |
| Size: 177mm x 125mm x 54mm Weight: 1.5kg |
1. Reserve 1*4pin CPU Fan Interface 2. Support hardware reset function(256levels,0-255 seconds) |
1 x Mini PC, 1 x Power Adapter, 1 x Power Cord, 1 x HDMI Cable, 1 x Screws Bag |
